TeamGroup T-Force Vulcan DDR4 3000MHz CL16 RAM Review

Vulcan
  • Editor Rating
  • Rated 4.5 stars
$$119.99
  • 90%

  • Vulcan
  • Reviewed by:
  • Published on:
  • Last modified: March 11, 2017

T-Force Vulcan is a low-profile DDR4 RAM by TeamGroup available in frequncies up to 3000MHz and 32GB kits. The asymmetrical design on the RAM looks very aggressive and appealing to the eyes. and the color scheme is perfect to fit most of the motherboards out in the market. But how does it compare in performance? Check out in the review below.



Today on the test bench, we have a very flashy and sleek looking RAM for review. Today we are discussing the TeamGroup T-Force Vulcan DDR4 RAM. The Vulcan is the name of the product and T-Force is a new lineup from TeamGroup. T-Force Series by TeamGroup consists of DDR4 memory modules and SSDs and are focused towards the gaming and overclocking enthusiast market.
The sample we received from their T-Force Lineup is the Vulcan DDR4 16GB 3000MHz CL16 RAM. The Vulcan RAM is the only low profile RAM in the T-Force line-up and features an asymmetrical aluminum heat spreader. The aggressive look of the RAM really stands out.

T-Force Vulcan Unboxing:


So, we received the RAM in a plastic container, except it was placed in a flat cardboard box for shipping purpose. But in a Plastic container is how you will get the RAM in a local store. And since the Plastic container is transparent, you can see the RAM in all its beauty without needing to take it out. And the aggressive looks of the RAM are sure to catch your eyes among the mass. Also, one of the RAM has the information sticker on the front so you can even check out the specs.

Nothing fancy on the back. Just an introduction of the T-Force and some features of the Vulcan RAM.

Once you take the RAM out of the box, you will come across a warranty policy booklet along with the RAM. The T-Force Vulcan comes with a life-time warranty. So with TeamGroup’s back, your RAM is going to outlast your numbers of system upgrades.

When you take out the RAM, and feel the Aluminum heat spreader and look at the design, you know you’re holding art in your hand. The asymmetric design is a pleasing view with inverted color separated from between. And on one side we have Vulcan and on other side T-Force logo in a beautiful red-black accent. Also, yes, this is a low-profile RAM, so you won’t have any trouble with most of the standard sized CPU coolers in the market.

Same design on the back, but just with the information sticker attached. On the information label, we can see the capacity per stick, MHz, CL timing, voltage, W/N and the model number.


And on the top, we have TeamGroup and their logo on both ends. Also, if you notice, there’s a silver line on both sides on half of the top. These lines represent a cut on the top, they are not a single piece, and that silver line is not graphics. So yes, you can pull the head spreader from the top and end up bending the heat spreader. This is a huge off for the people who have many occasions where they have to handle the RAM physically. But for overclockers, this might be a good thing as they won’t really need any tool to remove the heat spreader from the RAM so they can install their cooling solutions on the RAM. Just pry it off, and you’re good, but then, it means they won’t be able to re-install the heat spreader back because it would be too bent. I would rather see a heat spreader with screws which makes it easier for using in later occasions.

Some more pictures for eye candy:

T-Force Vulcan Specification:

ITEM SPECIFICATION
Module Type 288 Pin Unbuffered DIMM Non ECC
Capacity 4GB / 4GBx2 / 8GB / 8GBx2 / 16GB / 16GBx2
Frequency 2400 2666 2800 3000
Data transfer bandwidth 19,200 MB/s

(PC4 19200)

21,328 MB/s

(PC4 21300)

22,400 MB/s

(PC4 22400)

24,000 MB/s

(PC4 24000)

CL-Value CL14-16-16-31
CL15-17-17-35
CL15-17-17-35 CL16-18-18-38 CL16-16-16-38
Voltage 1.2V 1.35V
Heat Sink Aluminum heat-sink
Operation System Desktop or notebook computer with DDR4 Memory Slots
Required OS:Windows 10 / 8.1 / 8 / 7 / Vista / XP
Warranty Lifetime Warranty

The sample we are testing today is a 3000MHz kit running at 16-18-18-38-2T at 1.35v and is a 16GB (8GBx2) kit.

Test Rig:

Motherboard: Asus z170P
Processor: Intel I5 6600K 4.5GHZ OC
RAM: TeamGroup T-Force Vulcan 16GB 3000MHz CL16 DDR4
SSD1: Apacer AS720 240GB
SSD2: PNY Optima 120GB
SSD3: Kingston SSDnow V300 120GB
HDD: Seagate Barracuda 1TB 7200RPM
GPU: MSI R9 280X 3G
CPU Cooler: Thermaltake Water 3.0 ultimate
PSU: Chieftec Nitro 1200W 85+ bronze
Chassis: Thermaltake Core P3

Testing Methodology:

So first, the RAM will be tested with various benchmark softwares on the stock speed of 3000MHz at CL16 at 1.35 volts. These softwares include Aida64 Extreme Edition, MaxxMem, SuperPi 1.5, WinRAR Benchmark and PassMmark PerformanceTest 8. Then the RAM will be tested for overclocking capability. And if we can push the MHz higher, then after achieving the sweet spot of lowest voltage and CL timing, stress tests will be ran, and then the same benchmark software would be ran again.

First Boot:

The system booted without any issues once we installed the RAM. Also, we were running on the rated speed directly as we had XMP profile enabled. Then we ran some stress testing to ensure that the RAM is working fine.

Benchmark:

Aida64 Extreme Edition:

Click to enlarge

In the Aida64 Cache and Memory Benchmark, the Vulcan fall behind the almost same spec Apacer Blade RAM. But the lead is not too wide, it’s only behind by a few MB/s.

Click to enlarge

And as was expected, the latency is also a little higher than the competitor in the chart.

MaxxMem:

Click to enlarge

In the MaxxMEM benchmak, the T-Force Vulcan was able to take the lead in the writing speed, but it fall behind the the other Apacer Blade in other two sectors.

Click to enlarge

While the difference in the latency reading in the Aida64 benchmark is 1.5ns, here iti’s 1.4ns.

SuperPi Mod 1.5:

Click to enlarge

Since there’s not a big difference in the two RAMs in the top position, there’s only 1 second of difference in the Pi calculation.

PerformanceTest 8 – Memory Mark – Threaded:

Click to enlarge

In PerformanceTest 8, the T-Force Vulcan falls behind about 350MB/s.

WinRAR:

Click to enlarge

But in WinRAR benchmark, we see the Vulcan T-Force lacking behind with a difference margin of 300KB/s.

Overclocking:

This RAM played some games with my mind, but I was able to settle at a stable 3200MHz overclock at 1.4v on 15-16-16-38-2CR timings. And by games, I meant when I was testing the RAM for overclocking capability, and I started decreasing the voltage, I was able to boot at 1.23v at 3200MHz and was able to use the system without any issues for a few minutes (no stress test was run). What’s odder about this situation was that I couldn’t even get the RAM to work at 3333MHz at 1.45v. So the decreasing voltage headroom for 3200MHz just didn’t felt right. Assuming something’s wrong, I stopped the overclocking test right there. This has probably to do with the model of the motherboard, nothing’s wrong with the RAM.

Then the next day, when I decided to give it another go and started with stress testing, I started seeing BSODs very early till 1.32v. Then a little higher up, the XTU would crash the system till 1.36v. A little higher and I would get hardware failure errors in the Aida64 Stress test. And finally, after stress testing the RAM at 3200MHz at 15-16-16-38-2T at 1.4v, I was certain that this is the sweet spot for overclocking.

Once that was achieved, I tried 3333MHz again, but the system wouldn’t boot even at 1.45v, so I stopped there. A higher overclock might be still possible with the RAM if I were to play with the base clock of my CPU. And of course, overclocking headroom varies from stick to stick even if they’re from the same batch, so you might get different performance from your purchase.

Overclocking Benchmark:

Aida64 Extreme Edition:

Click to enlarge

Once overclocked, the T-Force Vulcan was able to beat the Apacer Blade at stock speed and in read speed when it was overclocked. But it still falls behind the overclocked performance of the Apacer Blade by a few MB/s.

Click to enlarge

In the latency, the T-Force Vulcan was able to beat the Apacer Blade by 0.87ns. Worth mentioned is that the Apacer Blade is running on CL14 while the T-Force Vulcan is on CL15 so it’s a good lead.

MaxxMem:

Click to enlarge

Same scenario in MaxxMEM benchmark results. T-Force Vulcan was able to beat the Blade at stock, but still falling short to beat the overclocked Blade RAM in sectors other than writing speed.

Click to enlarge


Surprisingly, the Blade came out in top in the MaxxMEM latency benchmark, but the difference isn’t too wide.

SuperPi Mod 1.5:

Click to enlarge

Whereas we saw the Vulcan falling behind in this benchmark by 1 second, once overclocked, the T-Force Vulcan came out in the top also by 1 second.

PerformanceTest 8 – Memory Mark – Threaded:

Click to enlarge

Almost same performance difference between the two contenders once overclocked compared to stock speeds.

WinRAR:

Click to enlarge

While the T-Force Vulcan was able to shorten the lead in the overclocked battleground in the WinRAR benchmark test.

Conclusion:

The TeamGroup T-Force Vulcan is for sure a wonderful RAM with great performance and aesthetic value. It gave the RAM with same specification a head to head battle without falling too much behind in the tests. The low-profile design makes it compatible with most of the CPU coolers in the market today. And it would fit perfectly with the MSI’s and Gigabyte’s Gaming, AsRock’s Fatality, and Asus’ Maximus series motherboard. But the top of the heat spreader is a gamble that might not end up well in situations like RAM handling and CPU cooler installation where the RAM heat spreader can be damaged.

Coming down to overclocking, there’s not much headroom as we’re already running at a very high frequency of 3000MHz at 1.35v. Compared to our previous RAM review which was running at the same frequency and voltage but different timings and was also able to achieve a stable overclock of 3200MHz just by increasing 0.2v, the T-Force Vulcan seems a little weaker in the overclocking sector. But once overclocked, the performance increase could be seen in the tests clearly.

In the end, it all boils down to the price of the product, and the TeamGroup T-Force Vulcan (same kit) is available on Newegg for $119.99. At this price range, this is one of the cheapest memory modules available in the market as of today, other than their own Delta and Dark RAM, which is even cheaper. At this price point and the performance, I would like to rate the TeamGroup T-Force Vulcan 4.5/stars and give it our Best Value award.
